Man & Machine C Mouse Mode D'emploi

• Operating Manual • Bedienungsanleitung • Mode d'emploi • Manual de usuario
• Manual do usuário • Istruzioni d'uso • Gebruikshandleiding • Installation
B
USB
2
Part functions:
EN
Micro USB port: Used to charge the mouse. Cover during washing or
1
rinsing. Cover is located on bottom of mouse.
Charging cable: Used to charge the mouse.
2
USB Port cover: Used to cover the Micro USB port during washing or
3
cleaning.
Power switch
4
Scroll Wheel
5
LED indicator: Red: mouse battery is charging, blinking blue: mouse is trying
6
to pair, solid blue: mouse is in paired mode and connected to computer.
USB Dongle: Plugs to a computer USB port. Allows the mouse to
7
connect to the computer wirelessly. The USB Dongle comes in the
mouse box with each mouse.
USB Port cover storage space: Keep the USB Port Cover in the storage
8
space when it is not used to cover micro USB port.
Sensor Light
9
Installation:
(See figure B.)
Plug the USB Dongle (7) into a computer USB port. Each dongle is
already paired with it's own mouse. Turn the mouse on (4). Wait for
mouse to pair automatically.
If you are using this mouse in combination with a Man & Machine
Wireless Its Cool keyboard or Wireless Its Cool Flat keyboard, you can
use one USB dongle to connect both devices. Once you have installed
the first device and it is paired, follow the pairing procedure to connect
the other device to the same dongle.
C Mouse Wireless
7
5
1
(See figure A.)
6
Pairing:
(See figure A.)
The mouse is already paired with the USB dongle that comes in the
mouse box. To pair the mouse with another dongle or to re-pair it with
the dongle it came with: turn on the mouse by pressing the power
button (4). Press the Scroll Wheel (5) and the Right Mouse Button at the
same time to put the the mouse in pairing mode. When the mouse is in
pairing mode, the Blue LED (6) will blink. If the USB dongle is plugged
in, unplug the USB dongle and plug it back to the PC. Keep the mouse
close to the USB dongle. Once the mouse is paired and connected to
the PC, the Blue LED will turn solid blue (6). Note: The mouse will not
work if it has lost it's pairing. Loss of pairing is signaled by blinking blue
light (6). Follow procedure described above to restore pairing.
Battery charging:
Connect the charging cable (2) Micro USB connector side to the mouse
and connect the USB A connector side to a 5V USB charging device
or a powered USB computer port. The Red LED (6) will stay on while
charging. The Red LED will go off when the battery is fully charged.
Remove and store the charging cable for future use.
Note: If the sensor red light at the bottom of the mouse doesn't come
on, charge the battery following the procedure described above.
Note: The mouse will not work if the battery is empty. Charge timely
following procedure described above.
Approved cleaning methods
• You can wipe the product with a soft cloth that is non-abrasive such
as a microfiber cloth, a disinfecting wipe, a soft brush similar to a paint
brush in bristle stiffness or a sponge, but not a scourer of any sort.
• You can spray the product with soap and water or an approved
disinfectant.
• You can rinse the product with soap and water or an approved
disinfectant. Before rinsing, cover port (1) with cover (3). Make sure
cover (3) is fully inserted (See figure A).
Approved disinfectants
• Chlorine based, up to 100,000 ppm (10%) bleach content
• Alcohol based
• Glutaraldehyde based
• Phenol based
• Formaldehyde based, up to 370,000 ppm (37%) formaldehyde content
• Oxidizing, such as Hydrogen Peroxide, up to 30,000 ppm (3%) content
• Quaternary Ammonium, up to 20,000 ppm (2%) content
5
9
(See figure A.)
4
3
8
A
