1. Items supplied

a) FBK 62 A (Fig. 1)
1 Hinged cold frame - assembled
1 Plastic assembly set
Replacement part no.: 36.804.10.02.019
(4 assembly corners, 4 earth anchors, 6 clips, 2
hood corner pieces)
2 Screws 2.9 x 6.5 mm
a) FBK 120 A (Fig. 2)
1 Side section, assembled (Fig. 2 / Pos. 1)
1 Double-sided hood, assembled (Fig. 2 / Pos. 2)
2 Plastic assembly sets (Fig. 3)
Replacement part no.: 36.804.10.02.019
(each with 4 assembly corners, 4 earth anchors,
6 clips, 2 hood corner pieces)
4 Screws 2.9 x 6.5 mm
2. Choosing a place in the garden
Choose a place in the garden for your cold frame.
The cold frame must be screwed to a level
foundation, or the ground must be level around the
area of the side panel, so that it can be fixed to the
ground with the earthing clamps (Pos. 8).
3. Assembly
For the purposes of assembly, you will need a light
hammer and some pincers.
3.1 FBK 62 A
Be sure to refer also to Fig. 1 for details of how to
assemble the FBK 62A.
a) (Fig. 4) Unfold the side section and slide the
aluminum profile (h) over the hinge (k) of the side
section on both sides. The hinge is thus fixed to the
upper edge.
b) (Fig. 5) Press the 4 lower corners of the side panel
into the assembly corners (5).
c) (Fig. 8) Slide the cover corners (6) onto both
corners of the cover.
d) (Fig. 8a) Fix the cover corners to the underside of
the cover with a 2.9x6.5 screw.
e) (Fig. 9) Push the clips (7) on the side halves.
Three openings can be inserted in each side of the
6
25.05.2005 9:47 Uhr Seite 6
cold frame. Preferably, one completely opened, one
completely closed and one individually adjustable
opening.
At the same time, the cover corners (6) are pushed
into the clips (7).
3.2 FBK 120 A
Be sure to refer also to Fig. 2 for details of how to
assemble the FBK 120A.
a) (Fig. 4) Unfold the side section and slide the
aluminum profile (h) over the hinge (k) of the side
section on both sides. The hinge is thus fixed to the
upper edge.
b) (Fig. 5) Push the four lower corners of the side
section (1) and the connecting profile (11) into the
assembly corners (5).
c) (Fig. 6) On both sides of the cover, push an
assembly corner (5) into the groove (b) on the
aluminum profile. Fold down the cover.
d) (Fig. 7) On both sides of the side panel, push the
assembly corner (5) into the groove (c) on the central
aluminum profile.
e) (Fig. 8) Slide the cover corners (6) onto both
corners of the cover.
f) (Fig. 8a) Fix the cover corners to the underside of
the cover with a 2.9x6.5 screw.
g) (Fig. 9) Push the clips (7) on the side halves.
Three openings can be inserted in each side of the
cold frame. Preferably, one completely opened, one
completely closed and one individually adjustable
opening.
At the same time, the cover corners (6) are pushed
into the clips (7).
