Rear Panel; Technical Data - FAME MS 5004 Manuel D'utilisation

1: Power Connection for IEC cable
2: Speakon Output
Exclusively use fully functioning cables in perfect working condition! Please ensure that
the rated performance of your speakers is suffi cient.
Model MS 5004
Capacity 8 Ohm 4x 350 Watts
Stereo Operation
Capacity 4 Ohm 4x 520 Watts
Stereo Operation
Capacity 8 Ohm 1040 Watts
Bridge Operation
Frequency 20Hz - 20KHz ± 0,5dB
(Bypass)
Input Sensitivity 1 Vrms @ 4 Ohm
Signal to Noise ≥ 102dB
THD 50% Pmax 0,02%
(1KHz)
Damping Factor >200
(1KHz)
Class H
Cooling System 2 Phase Fan
Power Supply AC: 230V 50-60Hz
Weight 18,3Kg

Rear panel

5: Line Input XLR
6: Mode Switch (Bridge, Stereo)

Technical Data

MS 8004
4x 550 Watts
4x 820 Watts
1640 Watts
20Hz - 20KHz ± 0,5dB
1 Vrms @ 4 Ohm
≥ 102dB
0,02%
>200
H
2 Phase Fan
AC: 230V 50-60Hz
19,6Kg
9
