2. General Information

Bike Parts
16
15
14
13
12
11
1
2
3
EN

Meaning of Icons

Indicates how to use the
product or items that
require special attention.
4
17 18 19
9
4 5 6 7 8
Life-threatening danger if
Incorrect action could
result in damage to the instructions are not
equipment. followed or preventive
measures are not taken.
1. Wheel
20 2. Cassette
3. Rear Derailleur
4. Chain/Belt
21
5. Chainring
6. Motor
7. Crankset
22
8. Pedal
9. Brakes
10. Fork
11. Carrier/Rack
12. CE Frame Sticker
10
13. Battery
14. Battery Lock
15. Seat Post
16. Saddle
17. Frame Joint
18. Frame
19. Handlepost Joint

20. Handlebar

21. Handlepost
22. Headset
You must have the proper tool, such
as a torque wrench for items that
require a specific torque. A torque
that is too high or too low can cause
parts to fall off or break and can lead
to serious accidents and injuries.
Handlebar
2
1
3
1. Controller/Display
2. Light
3. Handlebar
4. Brake Lever
5. Shifter
4
5
