Tv Operation - Panasonic PV-20DF25-K Mode D'emploi

TV Operation

RAPID
TUNE
MUTE
INPUT
ACTION
SELECT
▲▼◄►/
SET
CH▲▼
AV Input Terminal 2
Selecting Input Mode
Method 1:
Press CH ▲▼. The display will change as follows.
Notes:
• The diagram at right is an example.
• TV CH 2 and CABLE CH 1 represent
the lowest channels in memory,
while TV CH 69 and CABLE CH 125
represent the highest channels in
memory.
16
All manuals and user guides at all-guides.com
NUMBER
keys
100 key
VOL+/-
LINE2
(TV)
CH2
(CABLE)
CH1
(TV)
CH69
(CABLE)
LINE1
CH125
Method 2:
Press INPUT. The display will change as follows.
LINE1
Method 3:
1
Press ACTION for MAIN MENU.
2
Press ▲▼◄► to select "TV", then press SET for
SET UP TV screen.
3
Press ▲▼ to select "INPUT SELECT," and then
press SET to select "TUNER", "LINE 1", or "LINE 2."
4
Press ACTION twice to exit this mode.
LINE 1:
Signal of source connected to AV Input terminal 1 is displayed.
(Rear of the unit.)
LINE 2:
Signal of source connected to AV Input terminal 2 is displayed.
TUNER:
Signal of source connected to VHF/UHF terminal is displayed.
Using the CH/VOL Button
Select desired channel:
Press CH ▲▼ or NUMBER keys.
Adjust desired volume level:
Press VOL + or VOL -.
Using the Number and 100 keys
When selecting CABLE channels 100 to 125 with the NUMBER
keys, first press the 100 key, and then enter the remaining two
digits.
Example 1:
To select channel 125, first press the 100 key, then 2, then 5.
Example 2:
To select channel 12, first press the 1 key, then 2.
Example 3:
To select channel 2, first press the 0 key, then 2.
LINE2 TUNER
MAIN MENU
DVD LOCK LANGUAGE
TV CLOCK CH
SELECT: SET:SET
END :ACTION
SET UP TV
CAPTION
INPUT SELECT :TUNER
SET UP VIDEO/AUDIO
DVD VOL ADJUST :+2
SELECT: SET:SET
END :ACTION
