Display
Fig 13
Fig 15
Fig 17
26
A ps 2 3 0 A D VA N CE D Per s o n al S c o pe
Press 'mode' and select one of the screens
with the
pressing MODE repeatedly (see fig. 13 to
18).
Use the
markers or grid on the screen.
Fig 14
• A dot grid divides the screen into reference
• A full grid divides the screen into reference
• Markers: Moveable markers allow meas-
Notes:
Fig 16
Markers can also be accessed directly by
pressing the 'Marker 1-2' key.
Fig 18
DISPLAY SET-UP
or
key. You can also do this by
and
cursorkeys to view/hide the
points. (Fig. 14)
lines. (Fig. 15)
urement of the signal (Fig. 16).
TM
