System Connections

This section describes the typical system connections.

Using the Connectors

The connectors are in the inside of the rear cover.
When using the connectors, remove the rear cover, connect cables to the
connectors, and replace the rear cover.
To remove the rear cover
Pull the rear cover toward you.
To replace the rear cover
Align the four projections on the rear cover with the holes on the rear of the
unit, and press the cover.
