Assembly; Trimmer Guard; Fitting The Trimmer Head; Fitting The Loop Handle - Husqvarna 115iL Manuel D'utilisation

Trimmer guard

• Slide the trimmer guard into the trimmer head.
(Figure 34)
• Fasten the trimmer guard onto the housing to the
trimmerhead. (Figure 35)

Fitting the trimmer head

• Turn the output shaft until one of the holes in the drive
disc aligns with the corresponding hole in the gear
housing.
• Insert the locking pin into the hole to lock the shaft.
• Screw on the trimmer head in the opposite direction to
the direction of rotation.
• To dismantle, follow the instructions in the reverse
order. (Figure 33)

Fitting the loop handle

• Fit the screw into the loop handle.
• Slide the loop handle into the fitting on the shaft.
• Tighten the screw that secures the loop handle.
(Figure 36)
• Now adjust the trimmer to give a comfortable working
position. (Figure 11)

Fitting the plant guard

• Install plant protection in the holes on the trimmer
head. (Figure 37)
12 – English

ASSEMBLY
