Solid Concrete Installation
NOTE:
CPA adapter must be removed prior to
installing RSE to concrete. See Section 1a for
details.
1.
Determine mounting location.
WARNING:
a concrete ceiling with a minimum thickness of 8" and
a maximum drywall covering of 5/8".
WARNING:
RESULT IN SERIOUS PERSONAL INJURY OR
DAMAGE TO EQUIPMENT! Structural members
MUST be capable of supporting five times the
combined weight of all equipment being mounted.
Ø 6.3mm
2.
Using the RSE as a guide, mark four mounting hole
(Ø 1/4")
locations on ceiling using a pencil or similar tool.
3.
Drill four 1/4" (6.3mm) diameter pilot holes to a
depth of 2-1/2" (64mm) deep.
4.
Align four mounting holes in RSE with four pilot
holes.
IMPORTANT ! : Make sure mount is properly
oriented towards target before securing to
structure.
WARNING:
installed into structurally sound solid concrete.
X (4)
Installation into hollow concrete block, mortar, or
concrete that exhibits cracking, spalling, or other
5
defects may result in failure of anchor and serious
personal injury or damage to equipment.
5.
Install four 3/8" x 2-1/4" concrete anchors (not
(A)
included) by inserting into pilot holes and pounding
in until flush with mounting surface.
6.
Secure RSE to structure using four #10 flat washers
and four #10 x 3" Phillips head wood screws. (not
included)
X4
6
Installation Instructions
The RSE is designed to be mounted to
IMPROPER INSTALLATION CAN
Anchors (not provided) must be
