S+S Regeltechnik RHEASGARD KHSSF Serie Notice D'instruction page 9

G U
RHEASGARD
KHSSF x x
Housing
KHSSW x x
Housing
Type ⁄ WG01 Power
supply
KHSSF
K HSSF-W 24 V AC ⁄ DC
KHSSW
K HSSW-W24 24 V AC ⁄ DC
K HSSW-W230 230 V AC
changeover contact with automatic reset
Note:
(relay opens automatically when value falls below the threshold again)
AOS (Automatic Output Switching) = patented analogue interface (patent no. DE 10 2015 015 941 B4),
the unit automatically detects the required output type 0–10 V or 4...20 mA
®
KHSSF ⁄ RHEASREG
Output
active
AOS
0 -10 V ⁄ 4...20 mA
–
–
®
KHSSW
Output
switching
1 changeover contact
1 changeover contact
1 changeover contact
9
Rev. Data - V13
KHSSF x x
KHSSW x x
Item no.
1701- 5118- 0102-00 1
1701-5113- 0102- 001
1701-5133- 0102- 001
Probe
