Attach the Wall Mount Bracket (not included)
Before you begin the third-party manufacturer instructions, besure to do the following things:
1. Place the TV face down on a clean, safe and cushioned surface.
2. Remove the TV stand if you already attached it.
3. Place the spacers (not included) in the corresponding bracketholes.
CAUTION:
• When you attach the mount, be sure to use the spacers ( provided by the third-party
manufacturer ) between the TV and the bracket.
• To prevent internal damage to the TV and ensure it is mounted securely, be sure to use fixing
screws (not provided) that are 10 mm in length when measured from the attaching surface of
the mounting hook.
Rear cover of the TV
Wall mount hole pattern VESA (mm)
Wall mount screw size (mm)
Follow instructions provided with the wall mount bracket.
• To complete the installation, please contact the wallmount manufacturer or the retailer from
which you purchased the TV.
• The selected screws are 10 mm in length when measured from the attaching surface of the rear
cover. The diameter and length of thescrews differ depending on thewallmount bracket model.
NOTE: The diameter and length of the screws differed pending on the wall mount bracket
model.
Spacer(not
Bracket
provided)
(not provided)
10 mm
Wallmount bracket
Screw
Spacer
300 × 300
M6
7
Screw (not provided)
