Installation & Mounting :
6. Connect a Remote Turn-on wire from the head unit to the MTX amplifier's Remote terminal. If the head unit does not have a dedi-
cated Remote Turn-on lead, you may connect to the head unit's Power Antenna lead.
7. Connect RCA cables from the head unit to the MTX amplifier's RCA inputs. Run all signal cables away from vehicle wiring, computers
and power cables. If cables must be crossed do so at a 90° angle. Use only high quality RCA cables to decrease radiated noise from
entering the system.
8. Connect your speakers to your MTX amplifier's speaker terminals using the right gauge speaker wire. Two channels bridged can drive
a 4 ohm minimum load for max power. Channel 5 can drive a 2 ohm minimum load for max power.
9. Double check all previous installation steps, in particular, wiring and component connections. Once verified, reconnect the vehicle's
negative battery cable, turn the circuit breaker on or place the fuse in the fuse holder.
Note : Gain Levels on the amplifier should be turned all the way down (counter clockwise) before proceeding with adjustments.
Troubleshooting :
Problem
No LED indication
Power LED on, no output
Output distorted
Balance reversed
Bass is weak
Blowing fuses
How To Stay Tuned :
https://www.facebook.com/MTXEurope
https://twitter.com/MTXEurope
http://www.mtxaudio.eu
Cause
No +12V at remote connection
No +12V at Power connection
Insufficient ground connection
Blown power fuse
Volume on head unit off
Speaker connections not made
Gain control on amplifier off
Signal processing units off
All speakers blown
Head unit volume set too high
Amplifier gain set too high
Speakers wired reversed
RCA inputs reversed
Speakers wired out of phase
Not using MTX woofers
Excessive output levels
Amplifier defective
Solution
Supply +12V to terminal
Supply +12V to terminal
Verify ground connection
Replace fuse
Increase volume on head unit
Make speaker connections
Turn up gain
Apply power to signal processor
Replace speakers
Lower head unit volume
Lower amplifier gain
Wire speakers with correct
orientation
Reverse RCA input
Wire speakers with correct phase
Buy MTX woofers
Lower the volume
Return for service
