■ Mix in small quantities. Do not mix quantities larger
than usable in a 30-day period. A synthetic 2-stroke
lubricant containing a fuel stabiliser is recommended.
1 Litre
+
20 ML
2 Litres
+
40 ML
3 Litres
+
60 ML
4 Litres
+
80 ML
5 Litres
+
100 ML
Filling the tank
■ Clean
surface
around
contamination.
■ Loosen the fuel cap slowly to release pressure and to
keep fuel from escaping around the cap.
■ Carefully pour fuel mixture into the tank. Avoid spillage.
■ Prior to replacing the fuel cap, clean and inspect the
gasket.
■ Immediately replace fuel cap and hand tighten. Wipe
up any fuel spillage. Move 9 m away from refuelling
site before starting engine.
NOTE: It is normal for smoke to be emitted from a new
engine during and after first use.
WARNING
Always shut off engine before fuelling. Never add fuel to
a machine with a running or hot engine. Move at least 9
m (30 ft.) from refuelling site before starting the engine.
Do not smoke.
STARTING AND STOPPING
See figures 7-10.
WARNING
Never start or run the engine inside a closed or poorly
ventilated area; breathing exhaust fumes can kill.
NOTE: Before starting the unit, make sure:
● the On/Off switch is in "I" position;
Follow the instructions on the machine or described earlier
in this manual.
English(Original instructions)
=
50:1 (2%)
=
50:1 (2%)
=
50:1 (2%)
=
50:1 (2%)
=
50:1 (2%)
fuel
cap
to
prevent
To stop the engine
1.
Release the trigger.
2.
Push the switch to the "O" (OFF) position.
CUTTING TIPS
See figure 11.
■ Keep a firm grip with both hands while in operation.
■ If grass becomes wrapped around the string head,
stop the engine, disconnect the spark plug wire, and
remove the grass.
■ Use the tip of line to do the cutting; do not force string
head into uncut grass.
■ Wire and picket fences cause extra line wear, even
breakage. Stone and brick walls, curbs, and wood may
wear line rapidly.
■ Avoid trees and shrubs. Tree bark, wood moldings,
siding, and fence posts can easily be damaged by the
line.
TRANSPORTING THE UNIT
■ Drain all fuel from tank into a container approved for
fuel. Run engine until it stops.
■ Push the On/Off switch to the "O" (off) position.
■ Allow the engine and exhaust to cool before placing
in the vehicle.
■ Secure the unit against falling or sudden movement.
GENERAL MAINTENANCE
WARNING
Use only original manufacturer's replacement parts,
accessories and attachments. Failure to do so can
cause possible injury, poor performance and may void
your warranty.
WARNING
Before inspecting, cleaning, or servicing the machine,
shut off engine, wait for all moving parts to stop, and
disconnect spark plug wire and move it away from
spark plug. Failure to follow these instructions can
result in serious personal injury or property damage.
■ Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types
of commercial solvents and may be damaged by their
use. Use clean cloths to remove dirt, dust, lubricant,
grease, etc.
■ You may make adjustments and repairs described
here. For other repairs, have the trimmer serviced by
9
