Maintenance
(Draining Water and Flushing)
EN
If you are not going to use your Nano for an extended period of time, because the hygine reason, We recommend
you to drain it as follows.
Power OFF Prepare a pot
1 2
Disconnect Nano from the power socket For the drained water, use a pot or bucket
before moving it. If necessary, disconnect with a capacity of at least 1 liter.
the inlet water.
11
What to do when you start to use Nano after a long period:
1 Power ON 2 Prepare a pot
Plug in Nano. If you disconnected the Take a bucket or pot for the flushing water
water, reconnect it. under the tap.
11
22

Technical Specifications

Drain it
3
Hold Nano over the pot and remove the
drain cap. After the water has drained
out, replace the drain cap.
3 Flush it
Push the ROOM button and let out 5 liter
then push the COLD button and let out
another 5 liter water for flushing.
Average power consumption with 4 users
Smart Energy Saver mode ON
Basic operation
32 kWh
Base functionality
Hot, Cold, Room temperature water
Cold, cooling
60W Thermoelectric cooling, 4-15 Celsius (adjustable), 1.5 l/h cooling capacity
Hot, heating 2300W Ultra-efficient flow trough heater, 80-90 Celsius output, 0.5 l/min flow
Room temp. Direct outflow, 2 l/min flow rate
Interface
Capacitive touch interface with OLED screen
Connectivity
Bluetooth and WiFi
Materials
Tempered Glass, Anti-fingerprint coated interface, Aluminum & plastic housing
Inlet water requirements
Pressure range 2 -7 bar (30-100 psi) , Temperature range: 10-28 Celsius
Note: the inlet water must meet local drinking water regulations.
Room air condition requirements
10-35 Celsius range (note: Air temperature affects the cooling speed and efficiency!)
Filtration (optional) 5700 liter or 6-12 month lifetime (6 month NSF, 12 month is the manufacturer recommendation)
>0.2 micron particular reduction, chlorine, taste & odor reduction
bacteria, cyst, scale, asbestos reduction
Certifications: NSF42 & NSF53
Voltage & Power
230V/50Hz, maximum 2400W power consumption
Size & Weight
140x300x330mm (WxDxH), 4,5kg
Smart Energy Saver mode OFF
Cooling Heating Basic operation
31 kWh 23 kWh Total 35 kWh
86 kWh
Cooling Heating
105 kWh 23 kWh Total
163 kWh
