INSTALLATION
If your car is equipped with ISO connectors, simply
insert them in connectors of the car radio. If not,
you can use an adaptor cable (Refer to the table
on the separate installation card). Ensure all cables
are installed so that they cannot be damaged by
sharp edges or moving parts.
PREPARATION
a ei
Voltage and polarity: The set must be connected
to a 12V car battery with negative terminal to
earth (car chassis). Installation in vehicles not
fulfilling these requirements could result in
malfunction, damage or fire.
Warning: To 'prevent short-circuiting, disconnect
'the negative car battery terminal until the set has
been mounted and connected (fig.1 See separate
installation card). °
CONNECTOR A (fig.2)
Recommended Power supply connections
* Red lead A7 : Connect to a switched 12V supply
(switched on/off by car ignition). This is the main
power supply. Ensure this connection can handle
a current of 10A.
« Yellow/red lead A4 : Connect to a permanent
12V supply.
¢ Brown lead A8: Connect to earth (car chassis).
Alternative Power supply connections
+ Red lead A7 : Connect to a permanent: 12V
supply. This is the main power supply. Ensure
this connection can handle a current of 10A.
¢ Yellow/red lead A4 : Connect to a switched 12V
supply (switched on/off by car ignition).
+ Brown lead A8: Connect to earth (car chassis).
~ See INITIAL SETTINGS; select Option 'LOGI'
and set the choice to 'ON'.
This connection set up will enable you to make
full use of the ON/OFF LOGIC function of this set
limiting the use of the set to 1 hour after removal
of the ignition key. If this feature does not appear
' to be functioning as expected you may require
an adaptor cable (EA6259). See reverse of
installation card.
* Depending on version
OPTIONAL CONNECTIONS (fig. 2)
« Biuelead A5 (Electronic/Motor Aerial). se
This radio can provide a 12V signal for th
control of an automatic motor aerial or th
supply of an electronic aerial by connection.
Do not use this connection for.the supply lea
of the aerial motor!
* Orange lead AG (Pilot light) X : Connect i
the dashboard illumination wiring of the car.
When the car headlights are switched on, tk
backlight to the power key remains illuminate
(even when the radio is switched off). Whe
the set is on with this connection , th
brightness of the display is reduced.
CONNECTOR B (fig.2)
Loudspeakers (use 4 ohm loudspeakers onh
« Do not connect any of the loudspeaker leads |
earth or directly to a booster/amplifier or via <
external fader!
¢« Connecting 4 loudspeakers
Front Rear
Left+ Green [B5] White [B7]
Left- Green/black [B6] _White/black [Bé
Right+ Grey [B3] Blue [B14]
Right- Grey/black [B4] _ Blue/black [B2]
BLUE CONNECTOR C * for a HSS»)
compatible CD changer (available separatelh
(fig. 3)
* You can only connect (see mounting instructior
for the CD changer) the following CD chang:
to this set:
- ARC047 or ARC026 or ARCO32
* Portable player (fig.4) : You can connect
portable DCC, CD or cassette player to this si
(instead of the CD changer). The cable must k
connected to an output of 750mV (in most case
the headphone output of the portable player.
suitable).
— Refer to INITIAL SETTINGS'; select Optic
'SRC' and set the choice to 'AUX'.
— This indicates to the set that a portable player
connected instead of a CD changer.
— Increase the volume of the portable player °
desired level.
Complies with 21 CFR 1040.1
