Dimensions in mm
dTLS 85 luminaire
dTLS 85 luminaire with
compensating capacitor box
L218 mounting stirrup
X = fixing dimensions
8
Explosion protected light fittings
Type: dHLS 85 and dTLS 85
1
Technical data
1.1 dHLS 85...
EC type examination certificate:
Marking acc. to 2014/34/EU
and standard series
IECEx Certificate of Conformity:
Category of application
standard series
* depending on lamp
Compensation box eKG 84
EC type examination certificate
Marking acc. to 2014/34/EU
and standard series
Rated voltage
Rated current
HME 250 W (mercury vapour high-pressure lamp) 85250
HME 400 W (mercury vapour high-pressure lamp) 85400
HIE 250 W
(metal vapour high-pressure lamp)
HSE 250 W
(sodium vapour high-pressure lamp)
HSE 400 W
(sodium vapour high-pressure lamp)
Incandescent lamp 150 W
ϕ 250 W
Power factor:
ϕ 400 W
Perm.ambient temperature in original packing
Permissible ambient temperature
(*dHLS 85, 400 W +50 °C)
Degree of protection to EN/IEC 60529
Insulation class to EN/IEC 61140
Cable entries (KLE) (standard version)
Terminals
Between connecting wires keep an distance of >5 mm at 250 V
Test torques
Pressure screw of KLE M25
Terminals
Cover screws
Material
Housing colour
Weight (standard version)
Illuminant
DMT 03 ATEX E 039
II 2 G
EN 60079:
Ex de IIC T* Gb
IECEx BVS 11.0066
IEC 60079:
Ex de IIC T* Gb
BVS 03 ATEX E 106X
II 2 G
EN 60079:
Ex eq IIC T6
230 V +6 / - 10 %, 50 / 60Hz
Type
induct.
2.20 A
3.25 A
85250
3.00 A
85250
3.00 A
85400
4.40 A
85150
0.65 A
0.5
0.6
-50° C up to +55° C
-50° C up to +55° C*
IP 65 (standard version)
I - is complied with by the luminaires
2xM25 1x Ø 8 -17mm, 1x screwed plug
each terminal 2 x 1.5 - 4.0 mm² (L+N+PE)
5.0 Nm (for min. cabel Ø)
3.5 Nm (for max. cabel Ø)
2.5 Nm
5.5 Nm
housing
Cast light metal with special paint
bezel ring
Grey cast iron with special paint
Grey (RAL 7032)
approx. 30.0 kg (without compensation box)
approx. 37.0 kg (with compensation box)
to 400 W
HME - Mercury vapour high-pressure lamp
to 250 W
HSE - Sodium vapour high-pressure lamp
to 250 W
HIE - Metal vapour high-pressure lamp
to 150 W
Incandescent lamp
GB
compens.
Temp.cl.
1.10 A
T3
2.50 A
T3
1.50 A
T3
1.50 A
T3
3.00 A
T3
T3
0.8
0.8
