DEPTH OF CUT
See Figures 15 - 16, page 16.
Depth of cut is important because it affects the rate of feed
that, in turn, affects the quality of the cut and the possibility
of damage to the tool's motor and bit.
A deep cut requires a slower feed than a shallow one. A cut
that is too deep will slow the feed so that the bit is scraping
rather than cutting. A too deep cut can cause smaller bits
to be broken off. Bits that are 1/16 in. in diameter are easily
broken off when subjected to too much side thrust. A large
enough bit is not likely to break, but attempting a cut that
is too deep may result in a rough cut, and it may be difficult
ADJUSTING LOCK LEVER TENSION
See Figure 17, page 16.
Over time and with repeated use, the lock lever may
become loose. When this occurs, tighten the stop nut
slightly. The elastic stop nut should be loose enough so
that there is some play in the lock lever when it is in
the open position.
OPERATION
to guide and control the bit as desired. It is recommended
that you do not exceed 1/8 in. depth of cut in a single pass,
regardless of the bit size or the softness or condition of the
workpiece.
To make deeper cuts, make as many successive passes as
needed, lowering the bit 1/8 in. for each new pass. To save
time, perform all the cutting necessary at one depth setting
before lowering the bit for the next pass. This will insure a
uniform depth when you complete the final pass.
NOTE: Do not remove more than 1/8 in. in a single pass.
Excessive depth of cut can result in loss of control and the
possibility of serious personal injury.

ADJUSTMENTS

NOTE: Do not over tighten the elastic stop nut. The lock lever
should clamp tightly to secure the motor housing.
NOTICE:
Make sure the motor housing does not move up or down
when clamped. If motor is not securely clamped in base,
adjustments will not be accurate.
11 − English
