Back View
10 9 8
7
Power Supply
USING AC ADAPTER
Using an AC adaptor other than the one supplied
with the unit may damage the unit. This AC adaptor
operates on AC 120 V~ 60Hz.
CAUTIONS:
• Before use, ensure the rated voltage of the adaptor matches your local voltage.
• The included AC adaptor is for use with this unit only. Do not use it with other equipment.
• If you are not going to use the unit for a long time, disconnect the AC adaptor from the wall outlet.
• Whenever the AC adaptor is plugged in to a wall outlet, electricity is running through the
unit, even when the power switch is turned off.
• To prevent electrical shock don't inset a Polarized plug into any outlet unless all blades can
be fully inserted and unexposed after insertion.
Playback via bluetooth® enabled devices
The unit can be paired and connected to the Bluetooth® enabled devices such as a smart phone.
Note : You must disconnect the LINE IN cable and device from the unit when you are ready to
pair and connect your Bluetooth® device.
INITIAL DEVICE PAIRING AND CONNECTION
In order to pair and connect your Bluetooth® device for the first time:
1. Press the Power button to turn on the unit. Press the Fn button to Bluetooth® mode.
• The Bluetooth® indicator light glows blue and flashes which means the unit is in Bluetooth®
mode and ready to pair.
2. Turn on the Bluetooth® device you wish to pair and connect.
3. Press and hold the PAIR button on the unit. The Bluetooth® indicator light will start flashing
rapidly which means it is pairing.
4. On your Bluetooth® enabled device, search for the"RAS2866B2" in the list of discovered
7 FM radio antenna.
8 USB Charger: For charging only.
9 Line in Jack : Ø3.5mm jack for external
audio sources.
10 DC IN 13 Jack.
To AC Outlet
ac adapter
To "DC IN
13V" jack
devices and select it. It may take the unit and Bluetooth® enabled device a few seconds to pair.
5. When the Bluetooth® indicator glows a solid blue, the unit and the Bluetooth® enabled
device are now paired and connected.
6. You can now enjoy audio from the unit.
• The unit can only be connected to one Bluetooth® device at a time.
• If your Bluetooth device (e.g. Smart phone etc.)need the PIN code while pairing, please
enter 4-digit number: 0000.
RECONNECTING A BLUETOOTH® ENABLED DEVICE.
Bluetooth® enabled devices must be reconnected when the device has been turned off or the
unit has been turned off.
1. Turn on the Bluetooth® device that has already been paired with the unit.
2. Press the Power button to turn on the unit. Press the Fn button to Bluetooth® mode.
3. Depending on your Bluetooth® device, your device may automatically connect to the unit.
• If the device does not automatically connect to the unit, press and hold the PAIR
button on the unit until the Bluetooth® indicator light starts flashing rapidly,
then search for the "RAS2866B2" in its list of your Bluetooth® devices and select it.
4. Once the Bluetooth® indicator turns a solid blue, the Bluetooth® enabled device is paired
and connected.
PAIR AND CONNECT WITH ANOTHER NEW DEVICE
In order to pair the unit to a new device, you must first disconnect the currently paired and
connected Bluetooth® device from the unit.
1. On the currently paired and connected Bluetooth® device, select the "RAS2866B2" from the
list of currently paired and connected devices, and disconnect it. Please refer to your
Bluetooth® enabled device User's Guide for direction on how to disconnect a device. Or turn
off it.
2. Follow the Initial device pairing and connection instructions above.
1. Turn your unit on by pressing Power button on the unit, and press Fn button to select the FM
radio mode.
2. Press / buttons to select frequencies, Press and hold
next available station.
3. Press +/- buttons on the unit to adjust the volume.
Line in connection
Connecting to line in for other sound sources.
You can connect audio devices such as your CD player or MP3 player to the unit via the
LINE IN jack. To do this, connect an audio cable from the line out or headphone out jack
of the other audio device to the LINE IN jack on the back of unit
Note:
1. We recommend you unplug the device from the LINE IN jack when not in use.
2. Line-in is priority.
EN-2
Radio
/ to start auto searching for the
