Paradigm Cinema 100 3.0 Mode D'emploi page 12

WALL MOUNTING WALL MOUNTING
VERTICAL MOUNTING
FOR CINEMA ™
Position bracket and ensure it is level. Mark the two center screw holes. Drill pilot holes, then press
anchor bolts firmly into drywall and screw in. Follow with flathead screws: DO NOT SCREW ALL THE
WAY IN AT THIS POINT—leave screw heads protruding slightly.
Step 2
Bracket is slotted (see illustration), to allow further adjustment up or down, if necessary. Re-check to
ensure bracket is level. Mark inner screw holes.
11
(CONTINUED) (CONTINUED)
200, 400 TRIO
Position bracket vertically
on wall as shown, then
follow the steps for
horizontal positioning.
WARNING! For stability, all four
screws MUST be used
HORIZONTAL MOUNTING
FOR CINEMA ™ 200, 400
Wall screws not supplied
NOTE: This step is for
positioning only. Screws
will be removed in next
step to allow installation of
Step 1
additional anchor bolts
TRIO
