REPLACE THE GLASS RETAINER
Position the glass retainer, as shown in the figure 6.19. It should sit on the bottom edge
1.
of the outer glass. Check that the clamps "M" are not deformed or damaged.
2. Gently push the glass retainer back into place. You should be able to hear the tabs on
both sides click as they lock the glass retainer in.
Important !
Make sure the glass retainer is correctly and firmly in place and that the glass pane is
secure.
2
Click
M
M
Fig. 6.19
200
1
1
M
2
Click
