Max Cool

The Max Cool feature assists with periods of high refrigerator

use, full grocery loads, or temporarily warm room temperatures.

To turn on the Max Cool feature, press MAX COOL. When the

■

button is pressed, the icon will blink three times and appear

on the display screen.

To manually turn off the Max Cool feature, press MAX COOL

■

and the display will blink three times and turn off. The Max

Cool feature will remain on for 24 hours unless manually

turned off. Adjusting the refrigerator temperature will

automatically turn off the Max Cool feature.

Max Ice

The Max Ice feature assists with increasing the cooling for the

freezer compartment in order to increase ice production.

To turn on or off the Max Ice feature, press MAX ICE. When

■

the button is pressed to turn the feature on, the icon will blink

three times and appear on the display screen.

To manually turn off the Max Ice feature, press MAX ICE.

■

The display will blink three times and turn off. The Max Ice

feature will remain on for 24 hours unless manually turned off.

Adjusting the freezer temperature will automatically turn off

the Max Ice feature.

NOTE: Setting the freezer to a colder temperature may make

some foods harder, such as ice cream.

Water Filter Reset

Displays the status of the water filter. To reset the water filter,

press MAX ICE and MAX COOL for 3 seconds. After countdown,

the Good icon will blink three times and remain lit.

NOTE: The water filter status lights on the internal controls will

let you know when to change your water filter.

Order Filter (yellow) — Order a replacement water filter.

■

Replace Filter (red) — Replace the water filter. While you are

■

dispensing water, "Replace" filter icon will flash constantly

from beginning to the end of dispensing. After 14 days without

replacing the Water Filter, the "Replace" filter icon will blink

seven times and an alert tone will sound three times, at the

end of dispensing. See the "Water Filtration System" section.

NOTE: "Replace" will remain illuminated if a filter reset is not

done.

Reset Filter — Touch MAX ICE and MAX COOL at the same

■

time on the temperature control display for 3 seconds to reset

water filter. The display will do a 3-second countdown and

then flash the icon and play a tone.

Energy Saver

Your refrigerator will turn off the vertical mullion heater and

dispenser heater when Energy Saver is enabled.

To turn Energy Saver on, press and hold ENERGY SAVER for

■

3 seconds. The Energy Saver icon will blink three times and

then remain lit as shown.

IMPORTANT: When Energy Saver is enabled and the LED is on,

the dispenser heater and vertical mullion heater will be turned off.

Press and hold ENERGY SAVER for 3 seconds again to turn

■

the heaters back on.

Sound On-Off

The Sound On-Off button allows the customer to turn the sound

on and off.

To turn on the Sound feature, press SOUND ON-OFF. When

■

the button is pressed, the Sound On-Off icon will blink three

times and appear on the display screen.

To manually turn off the Sound feature, press SOUND

■

ON-OFF and the display will blink three times and turn off.

Power Outage

The Power Outage indicator lets you know if the power supply

to the refrigerator has been off and the freezer temperature has

risen.

The "Power Outage" icon will illuminate and an alert tone will

sound three times. Touch any button to stop the tone and turn off

the Power Outage icon.

Once the power outage has been confirmed, "Power Outage,"

will disappear.

Showroom Mode

This mode is used when the refrigerator is on display in a retail

store or if you want to turn the cooling off, and deactivates all

other functions (except interior lighting). Showroom mode can

be used when going on vacation. See the "Vacation and Moving

Care" section for proper steps on leaving your refrigerator in this

mode for long periods of time.

If you turn on Showroom mode, the word "Showroom" will light

up on the display. Enter or exit Showroom mode by pressing and

holding °F/°C and DRAWER at the same time for 3 seconds.

NOTE: Empty ice maker if refrigerator is going to be turned off for

an extended period of time.

Sabbath Mode

Sabbath mode is designed to have all the benefits of saving even

more energy, yet maintaining food freshness. The freezer and

refrigerator user set points remain unchanged while in this mode.

If you unintentionally turn on Sabbath mode, the word "Sabbath"

will light up on the display. Enter and exit Sabbath mode by

pressing and holding °F/°C and SOUND ON-OFF at the same

time for 3 seconds.

NOTE: You will be unable to dispense or change temperature set

points in Sabbath mode. Your interior lighting and control panels

will all be inactive in Sabbath mode.
