ASSEMBLY INSTRUCTIONS
This heater is supplied with both wall mounting
brackets for fixed installation and castors for portability.
Portable Assembly
1. Position the heater carefully upside down and position the base supports over
the screw hole in the base of each end of the heater.
2. Secure with the 2 screws supplied
(1 screw per base support).
Fixed Installation
Refer to Minimum Clearances adjacent as a guide to the correct location of the
heater. Ensure the castors are removed and stored safely, if they are currently se-
cured to the heater.
1. Secure the 3 mounting brackets to the rear of the heater
by locating the top of each bracket into the 3 slots. Fix
each bracket at the base with the 3 small screws provided
2. Note: The bottom bracket is not required to be affixed to
the wall. It is a spacer to balance the heater when affixed.
3. Fix the heater to the wall by locating the bracket holes over
the screws then secure in place by slotting the screw into the
upper most fixing location on the bracket (slide to the right and up).
4. Ensure the heater is securely fastened to the wall.
16
top
bottom
