Please read and comply with these origi-
nal instructions prior to the initial opera-
tion of your appliance and store them for
later use or subsequent owners.
– Before first start-up it is definitely necessary to read
the operating instructions and safety indications Nr.
5.951-949.0!
– In case of transport damage inform vendor immedi-
ately.
– Check the contents of the pack before unpacking.
For scope of delivery see illustration 1.
– At operating elevations of approx. 800 m above
sea level or higher, please contact your dealer to
have the burner setting adjusted to the elevation
and reduced oxygen content.
Contents
Environmental protection
Overview
Symbols on the machine
Proper use
Safety instructions
Safety Devices
Start up
Operation
Storage
Transport
Care and maintenance
Troubleshooting
Warranty
Accessories and Spare Parts
EU Declaration of Conformity
Technical specifications
Environmental protection
The packaging material can be recycled.
Please do not throw the packaging mate-
rial into household waste; please send it
for recycling.
Old appliances contain valuable materi-
als that can be recycled; these should be
sent for recycling. Batteries, oil, and sim-
ilar substances must not enter the envi-
ronment. Please dispose of your old ap-
pliances using appropriate collection sys-
tems.
Electrical and electronic devices often contain compo-
nents which could potentially pose a danger to human
health and the environment if handled or disposed of in-
correctly. However, these components are necessary
for the proper operation of the device. Devices marked
with this symbol must not be disposed of with regular
household rubbish.
Please do not release engine oil, fuel oil, diesel and
petrol into the environment Protect the ground and dis-
pose of used oil in an environmentally-clean manner.
Notes about the ingredients (REACH)
You will find current information about the ingredients
at:
www.kaercher.com/REACH
Figure 1
1
2
3
4
5
6
7
8
9
10 High-pressure nozzle (stainless steel)
11 Pouring vent for detergent
12 Steering roller with fixed position brake
13 Fuel sieve
EN 1
14 Safety lever
EN 1
15 Power supply
EN 2
16 Trigger
EN 2
17 Tool bag (HDS C only)
EN 2
18 Safety latch of the hand spray gun
EN 2
19 Trigger gun EASY!Force
EN 3 20 Pressure/ quantity regulation at the hand spray gun
21 Pouring vent for fuel
EN 4
22 Dosage valve for detergent
EN 6
23 Operating field
EN 6
24 Storage for hand spray gun
EN 6
25 Connecting hose of the hose drum (HDS CX only)
EN 7
26 Step depression
EN 8
27 Hose drum (HDS CX only)
EN 8
28 Hand crank for hose drum (HDS CX only)
EN 8 29 Handle
30 Nameplate
EN 9
31 Cover lock
32 Storage compartment for accessories
33 Burner
34 Recess for spray pipe
35 Cover
36 System care RM 110/RM 111
37 Pressure/quantity regulation of the pump unit
38 Oil tank
39 Oil drain screw
40 Backflow valve of the detergent infeed
41 Detergent suction hose with filter
42 Fuel filter
43 Fastening clamp
44 Hose (soft damping system) of the water shortage
45 Water shortage safeguard
46 Sieve in the water shortage safeguard
47 Fine filter (water)
48 Float tank
Figure 2
A
0/OFF =
1
2
3
4
5
6
– 1
EN
Overview
Device elements
Support for spray lance
Manometer
Recess for detergent suction hose
Recessed grip (both sides)
Connection for water supply with filter
Water connection adapter
High-pressure connection EASY!Lock
High pressure hose EASY!Lock
Spray lance EASY!Lock
safeguard
Operating field
Power switch
Off
Operating mode: Cold water operation
Operating mode: Hot water operation (e = Eco
mode, hot water max. 60°C)
Operating mode: Stream operation
Indicator lamp rotation direction
(3-phase appliances only)
"Ready for use" indicator lamp
Fuel indicator lamp
