S+S Regeltechnik THERMASGARD 9111 Notice D'instruction page 16

G
Mounting and Installation
0V
Supply voltage
+10...+24V DC
RS485-Bus
Connections
0V
Power supply and bus line are pluggable. All other connections are screw terminals.
Power supply: ....................2-pole COMBICO plug connection
Bus connection: ................2-pole COMBICO plug connection
I ⁄ O connections: ...............Screw terminals designed for strands up to 2,5 mm
Power supply LED
The power supply LED is located at the front side of the device at the bottom left.
The green LED [Rx] signalises the presence of power supply.
Communication LED
The communication LEDs are located at the front side of the device at the top left.
The green LED [Rx] signalises data traffic on the bus line (arriving data).
The red LED [Tx] signalises that field bus device is sending data to the bus line.
Rx Tx
Configuration
The position of DIP switches is at the top, centred.
The bus termination is located between bus connector and DIP switches.
RS485 BUS TERMINATION
The terminating resistor for bus termination is already built-in in the device and
can be activated via jumper as needed.
RS485-Bus RS485-Bus
Busabschluss
Bus termination
0V 0V
offen
open
Busabschluss
BUS PROTOCOL
geschlossen
The bus protocol can be selected at the left DIP switch (position 8).
(aktiviert)
DIP switches, left:
Bus protocol Rx Rx Tx Tx
DIP 1 DIP 2 DIP 3
x x x
x x x
RS485 Bus
RS485 Bus termination
ON
1
Rx Tx
RS485 Busabschluss
Bus-
adresse
ON ON
1 8 1
Busabschluss
offen
Busabschluss
RS485 Busabschluss RS485 Busabschluss
Bus termination
geschlossen
closed (activated)
(aktiviert)
Bus- Bus- Busparameter Busparameter
adresse adresse (Baudrate, (Baudrate,
Datenbits,..) Datenbits,..)
ON ON ON ON
1 1 8 8 1 1
DIP 4 DIP 5 DIP 6 DIP 7
x x x x
x x x x
Bus Bus parameters
address (Baud rate,
data bits ...)
ON
8 8
1
Busparameter
(Baudrate,
Datenbits,..)
2
8
8 8
DIP 8 Protocol
®
ON Saia PCD S-Bus
OFF Modbus RTU
16
THERMASGARD ® 911x
