Connectors and Controls

1
MC
L
R
50-550Ω 50-550Ω
5
1
Phono input (MC)
2
Phono input (MM)
3
Phono ground connection
Note that this terminal must not be used as a safety earth
4
rPhono output
5
Left and right input loading resistance (MC only)
6
Left and right input loading capacitance
7
rPhono gain
8
Rumble filter
9
Phono cartridge type selector
10
Power switch
11
Power input connector
2 3
MM
R L
CAP
LOAD
120pF
220pF
340pF
440pF
6
4
OUTPUT
GAIN
30dB
L
40dB
50dB
52dB
R
7 8 9
POWER
12V 2.0A
1 0
10 11
E-3
