Theory Of Operation; Ventilation; Assembly - Desa RCLP50VA Manuel D'utilisation

The hose/regulator assembly attaches to the propane gas supply. This provides fuel
The Fuel System:
to the heater.
The motor turns the fan. The fan pushes air into and around the combustion chamber.
The Air System:
This air is heated and provides a stream of clean, hot air.
The Ignition System:
The Automatic Control System:
Clean
Heated
Air Out
(Front)

VENTILATION

WARNING: Provide at least
a 1.5 ft (0.14 m
2
fresh, outside air while running
heater. If proper fresh, outside
air ventilation is not provided,
carbon monoxide poisoning
can occur. Provide proper fresh,
outside air ventilation before
running heater.

ASSEMBLY

1. Remove screw from top of fan guard. Discard
screw.
2. Insert nut clip (provided with handle) with
flat side facing up through slot in top of shell.
Align holes in nut clip with screw hole behind
slot in top of shell. (see Figure 4).
Figure 3 - Removing Screw from Top of
Fan Guard
4

THEORY OF OPERATION

The piezo ignitor lights the burner.
This system causes the heater to shut down if the flame goes out.
Combustion Chamber
Air For Combustion
Figure 2 - Cross Section Operational View
) opening of
2
Remove
Screw
www.desatech.com
Fan
Air For Heating
Flat Side Facing Up
Figure 4 - Installing Nut Clip
Nut Clip
Figure 5 - Attaching Handle
Motor
Cool Air In
(Back)
Hose/
Regulator
Assembly
Nut Clip
Slot
Shell
Screws
Handle
Rear of
Heater
105339-01D
