Stick the EPDM seal around the hatch gap
3
(check the drawing for cutting the edges of
the gasket seal ).
HOW TO CUT THE EPDM SEAL TO AVOID
!
WATER LEAKING INTO THE CAB
A- Stick the seal, keeping 100 mm of pro-
tection paper on each side.
B- Remove the two pieces of paper.
C- Stick by pressing both ends.
B
Seal
Seal
Eliminate
3
A
Seal
100 mm Approx. (Protection paper)
C
Seal
20
®
15 mm
Seal
Cab roof
Seal
