Illuminated ON•OFF Key
The ON•OFF key powers components on and
ON•OFF
off. It also lights up to serve as an indicator
light, providing feedback for various functions.
When a valid key is pressed, the illuminated
ON•OFF key remains lit as long as the key is
ON•OFF
pressed and turns off when the key is released.
The ON•OFF key also blinks in Programming
Mode or in Menu Mode to provide feedback.
(BLINK)

Programming the Remote

Your universal remote can operate a variety of brands of
components. In order for your universal remote to control
your components, you need to program the remote with the
codes that match the components (See Code Lists enclosed).
These codes enable the remote to communicate with your
components. Each brand and each component has its own
"language," and, by programming the correct codes into your
remote, you tell the remote to "speak the same language"
as your components.
There are four methods you can use to program your remote
to operate your components: Brand Code Search and Entry,
Direct Code Entry, Manual Code Search and Entry, and Auto
Code Search and Entry. Most components can beprogrammed
in one of these four ways. Try them in the order listed.
In order to control combo units, like TV/VCRs or TV/DVDs,
you must program the individual corresponding component
keys to control each part of the combo unit. Once
programmed successfully, the TV key controls the TV
functions on your unit, and the VCR•DVD key controls the
VCR or DVD functions, respectively. There is a specific
section in the Code Lists for combo units. The codes in this
section should be tried first, using Direct Code Entry on the
TV and VCR•DVD keys. If this is unsuccessful, follow the
normal programming methods for both the TV and the
VCR•DVD keys.

Programming Methods

Brand Code Search and Entry

If your brand is listed in the Brand Code List (See Code Lists
enclosed), you may be able to program your universal remote
by searching through only the Code Lists for that specific
manufacturer. Brand Code Search and Entry can be the quickest
method to program your remote, if your component (TV, VCR
and/or DVD, satellite receiver and/or cable box) is one of
those brands listed.
If your brand is not listed in the Brand Code List, use one of
the other programming methods: Direct Code Entry, Manual
Code Search and Entry or Auto Code Search and Entry.
Follow these instructions to program your remote using
the Brand Code Search and Entry method.
! To exit without saving at any point in
GO BACK TIP:
the Brand Code Search, press and release the
GO BACK key.
1. Manually turn on the component you want the remote to
control (TV, VCR, DVD, satellite receiver or cable box).
2. Locate the Brand Codes in the Code Lists and keep it handy.
If you press an invalid key during the Brand Code
Note:
Search, the remote does not respond and the search times
out after two minutes. When the search times out, the
illuminated ON•OFF key blinks four times and turns off. The
last programmed code under that component key is retained.
4
7/27/04 11:46 AM Page 4
3. If you are programming the remote to control your TV,
satellite receiver or cable box, go directly to step 5.
4. To program the remote to control a VCR or DVD. The
VCR•DVD key can control only one component, either your
VCR or your DVD. To program your remote to control either
your DVD or your VCR, you must first put the remote in
the proper programming mode. Follow these directions
before proceeding to step 5.
a. Press and hold the VCR•DVD
• •
VCR DVD ON OFF
key. The illuminated ON•OFF
key turns on.
b. While holding down the
VCR•DVD key, press and
•
VCR DVD release the number 2 key on the
keypad to control a VCR or the
number 3 key to control a DVD.
The illuminated ON•OFF key
turns off.
c. Release the VCR•DVD key. The
•
ON•OFF
VCR DVD
illuminated ON•OFF key blinks
four times and then turns off.
Your remote is now either in
VCR or DVD Programming
(BLINK)
Mode, depending on which
you chose. Proceed to step 5.
•
VCR DVD
5. Press and hold the component key
•
TV
SAT CBL
(TV, VCR•DVD, SAT•CBL) you
ON•OFF wish to program. The illuminated
ON•OFF key turns on and
remains on.
(BLINK)
6. While holding the component key
•
ON OFF
down, press and hold the
ON•OFF key. The illuminated
ON•OFF key turns off.
7. After holding both keys down for
three seconds, the illuminated
ON•OFF key turns back on.
8. Release both keys. The illuminated
ON•OFF key remains on.
9. Refer to the Brand Codes in the
enclosed Code Lists. Press and
ON•OFF
release the appropriate brand code
key, using the number keys on the
keypad. The illuminated ON•OFF
key blinks once.
(BLINK)
Throughout the programming
! TIP:
of each key, be sure to keep the remote
pointed at the IR sensor of the
component you are currently
programming the remote to control.
10. Press and release the ON•OFF key
repeatedly until your component
ON•OFF
turns off. Wait 4 seconds between
each key press. Each time you press
the ON•OFF key, the illuminated
ON•OFF key blinks, and the next
ON•OFF
code is sent. The Brand Code
Search begins with the first code in
the chosen brand list for that
component and cycles through all
(BLINK) the codes for that brand. If your
component turns off, you have
found the correct code. (If it cycles
through and the illuminated
ON•OFF key blinks four times and
turns off, all codes in the chosen
brand lists have been searched. The
Brand Code Search mode is exited.)
5
