ADJUSTING THE DOORS
If the doors are not aligned in height, they can be adjust up to a maximum of 5 mm.
1. Fixed axis
2. Adjustable foot
3. Security nut
4. Adjusting nut
5. Spanner
1. Turn the security nut clockwise with a spanner to loosen it. (2 full rotations).
2. Now you can adjust the adjusting nut to raise or lower the door.
· The door is too low: turn the adjusting nut counter-clockwise to raise the door.
· The door is too high: turn the adjusting nut clockwise to lower the door.
3. Once the doors are correctly aligned, retighten the security nut.
www.domo-elektro.be
1
2
3
4
5
