WARNING
Risk of injury from ejected parts
► The cartridge and the saw blade must be
replaced.
Never use warped saw blades or saw
blades with cracked or broken teeth.
► Remove the table insert (see section
► Remove the spacer wedge (see section
► Turn the cutting height setting [4-2] to the
minimum of 0 mm and turn it further
against the resistance.
Turn the cutting height setting [4-2] to the
maximum of 80 mm.
The cutting height is set to the maximum of
80 mm.
► Turn the cartridge locking device [4-4]
clockwise by one quarter of a rotation and
pull it out [4-5].
► Undo the spindle nut [4-6] and remove the
flange [4-7] of the saw blade.
► Use the spanner [4-8] as a lever to carefully
push the saw blade out of the tool spin­
dle [4-10].
Use the spanner [4-9] as a lever to carefully
push the cartridge out of the fastening
pins [4-11].
Repeat both steps until the saw blade and
the cartridge have been successfully re­
moved.
► Fit a new cartridge (see section
► Fit a new saw blade (see section
► Fit the table insert (see section
► Fit the spacer wedge (see section
9

Additional settings/functions

WARNING
Risk of injury, electric shock
► Always disconnect the mains plug from the
socket before performing any work on the
machine.
9.1 Electronics
The TKS 80 EBS is monitored electronically
with the following properties:
Smooth start-up
The electronically controlled smooth start-up
function ensures that the power tool starts up
smoothly. The limited starting current ensures
that even standard household fuses are not
triggered.
Speed control
You can regulate the speed within the continu­
ously variable speed range using the adjusting
wheel [2-7] (see section
optimise the cutting speed to suit the respective
material.
Speed range per material
9.6 ).
Wood
9.8 ).
Laminate, mineral materials
Aluminium, plastic
The preselected motor speed is kept constant
through electronic control. This ensures a uni­
form cutting speed even when under load.
Overload safety device
The power supply is restricted if the power tool
is overloaded to extremes. The power supply is
disconnected completely if the motor jams for
some time. You will need to remove the load
and/or switch off the power tool before you can
use it again.
Temperature cut-out
To avoid the motor overheating, the power con­
sumption is limited at an excessive motor tem­
perature (e.g. if the pressure is too high while
working). If the temperature continues to rise,
the power tool switches off. It can only be
switched on again once the motor has cooled
sufficiently.
9.12 ).
Brake
9.11 ).
The saw blade is stopped electronically within
9.6 ).
approx. 3 seconds of switching off the machine.
9.8 ).
Restart protection
The built-in restart protection prevents the
power tool from starting up again automatically
if the power is disconnected during continuous
use. To put the power tool back into operation,
it must first be switched off and then on again.
9.2
Festool saw blades are identified by a coloured
ring. The colour of the ring represents the ma­
terial for which the saw blade is suited.
Refer to the necessary saw blade data (see sec­
tion
4
Selecting the saw blade
3.1 ).
English
). This enables you to
6
2–5
3–6
35
