OBJ_BUCH-965-009.book Page 13 Friday, December 9, 2016 3:18 PM

Product Features

The numbering of the product features shown refers to the illustration of the
measuring tool on the graphic page.
1 On/Off switch
2 Exit opening for laser beam
3 Spirit levels for vertical and horizontal alignment
4 Serial number
5 Spirit level for diagonal alignment
6 90° scale with 5° graduation
7 T-edge for alignment
8 Magnets
9 Battery lid
10 Bottom plate
11 L-edge for alignment
12 Latch of battery lid
13 Wall holder
14 Laser viewing glasses*
15 Laser warning label
* The accessories illustrated or described are not included as standard delivery.

Technical Data

Tile laser
Article number
1)
Working range
Angular accuracy
Operating temperature
Storage temperature
Relative air humidity, max.
Laser class
Laser type
C
6
2)3)
Laser line width
– at a distance of 3 m
– at a distance of 5 m
Batteries
Operating time, approx.
Weight according to
EPTA-Procedure 01:2014
Dimensions (length x width x height)
1)The working range can be decreased by unfavourable environmental conditions (e.g. direct
sun irradiation).
2)at 25 °C
3)The width of the laser line depends on the surface characteristics and on the ambient
conditions.
The measuring tool can be clearly identified with the serial number 4 on the type plate.
Bosch Power Tools
English | 13
PLT 2
3 603 F64 000
7 m
±0.5 mm/m
+5 °C...+40 °C
–20 °C...+70 °C
90 %
2
635 nm, <1 mW
1
<4 mm
<6 mm
3 x 1.5 V LR6 (AA)
15 h
0.36 kg
240 x 128 x 59 mm
1 609 92A 27J | (9.12.16)
