Parts identification
 











A Protective cap
B Outer foil section
1 System outer foil
2 System outer foil release
buttons
3 Foil frame
C Inner blades
D Main body
4 Foil frame release buttons




5 Switch lock button
6 OFF/ON switch
7 Appliance socket
8 Trimmer
9 Trimmer handle
E Charging adaptor (RE7‑5)
: Charging plug
; Charge indicator lamp
 Cleaning brush
Charging
Perform the following steps to charge the shaver if it seems to lose
the speed.
You can fully charge the shaver in 8 hours.
• A full charge will supply enough power for approx. 7 shaves of 3
minutes each.
1
1
Turn off the
shaver and
insert it in the
charging adaptor
as illustrated.
2
2
Plug in the
adaptor into a
household
outlet.
• The charge indicator lamp glows and stays on until the shaver is
removed from the charging adaptor.
3
