Gerätesteuerungen mit Reflex Control Remote und I/0‐Modul oder/und Busmodul.
1
Steuerung Control Touch mit Control Remote
2
I/0‐Modul
Jumper / Schalter
Einstellung
Control Remote
Control Touch
Control Basic
I/0‐Modul
Busmodul
• Lon Works
• Profibus DP
• Ethernet
Einstellungen der Abschlusswiderstände
Jumper J10 und J11
Aktiviert
Deaktiviert
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
X
‐‐
‐‐
Control Remote — 09.11.2015
3
Busmodul
4
Steuerung Control Basic mit Control
Remote
DIP‐Schalter 1 und 2
Aktiviert
Deaktiviert
‐‐
X
X
‐‐
X
‐‐
‐‐
‐‐
‐‐
‐‐
Einstellungen
Jumper J3
1 und 2 sowie 3 und 4
Aktiviert
Deaktiviert
‐‐
‐‐
‐‐
‐‐
X
‐‐
‐‐
‐‐
X
‐‐
Deutsch — 9
