REMIS REMIcare van Notice De Montage page 11

Step 5: (Adjusting the string tension, if necessary)
A20
A21
A22
A23
A24
OL OR
UL UR
A20+A21:
In order to adjust the string tension, loosen the grub
screw inside the string stretcher sitting inside the top gui-
ding profile, with a small 1.5mm Allen screw. Now pull hte
string stretcher towards the handle bar to stretch it more,
or into the opposite direction to loosen the tension. Pull the
grub screw tight again.
A22:
In order to first determine the position of the string stret-
cher inside the floor profile, carefully move your finger
along between the brushes of the floor profile. The string
stretcher is located inside the bottom canal of the floor
profile and is covered by the brushes.
A23:
Use a small 1.5mm Allen screw here, too, to loosen the
grub screw from inside the string stretcher. Pull the string
stretcher towards the handle bar to stretch the string more
and into the opposite direction to loosen the strings. Now
pull the grub screw tight again.
A24:
Make sure the handle bar is running parallel to the coffer
profile or the door sealing.
Note: When stretching or loosening the handle bar is adju-
sted in the following direction:
String stretcher
Top
Top
Buttom
Buttom
Attention: Pretention must not be too strong since
operating will be too stiff and, in the worst case, the
string may tear!
Pulling Direction
Loosening
X
X
X
X
US/GB
UR
UL
OR
OL
11/17
