Step 2: assembling the handlebar post and connecting the resistance and hand pulse cable
Put the handlebar post (25) in a vertical position. Place the plastic cover (37) over the lower part of the
handlebar post (25). Keep the upper hand pulse cable (28) hanging from the handlebar post until it is
connected.

Connect the upper hand pulse cable (28) with the lower hand pulse cable (45).
Connect the upper resistance cable (50) with the lower resistance cable (47) (see image below).

Put the handlebar post (25) in the main frame (68) and secure the handlebar post (25) with six allen
bolts (14), six spring washers (15) and six curved washers (13).


24
