3. Dimensions

Unité：pouce (mm)
The connective pipe
of restricted assembly
(accessories)
Modèle d'unité intérieure
5,6-8.0kW
10,0-14.0kW
37-13/32(950)
30-23/32(780)
2-5/32
(55)
A
pouce (mm)
9-1/16(230)
11-13/16(300)
4-1/8
(105)
Φ75New air
supply orifice
B
pouce (mm) pouce (mm)
6-11/16(170) 3/8(Ф9.53)
7-15/32(190) 3/8(Ф9.53)
7
KCIBF- DN3.0
Refrigerant pipe orifice(Liquid side C)
Refrigerant pipe orifice(Air side D)
Drain pipe outter diameter
33-1/16(840)
35-19/32(904)
C D
pouce (mm)
5/8(Ф15.9)
5/8(Ф15.9)
