Commissioniong
7

Multi-motor operation - without keypad

Danger!
Extremely dangerous voltage at power connections.
The device must be disconnected from the mains voltage when it is open.
l
Even if the starttec is inhibited (X3/28 = LOW), the connections 1V, 2V, B1 and B2
l
carry dangerous voltage!
Stop!
Without keypad, the type 2 starttec can only be set up for "multi-motor operation"!
l
Never try to set up the control mode "change of direction of rotation" without a
l
keypad. The starttec type 2 can be damaged!
Tip!
Potentiometer and switch settings always apply to both motors.
We therefore recommend to use the keypad for "multi-motor operation" because it is then
possible to individually set every motor.
With Lenze setting (C0006 = -0-), acceleration time (C0012), start voltage (C0016) and rated current
(C0120) can only be set via potentiometer or switch.
Step switch [S]
Position Rated
current
0 –
1 1.0 A
2 1.4 A
3 1.8 A
4 2.4 A
5 3.0 A
6 4.0 A
7 5.5 A
8 7.0 A
9 9.5 A
30
Motor power at mains voltage
230 VAC 400 VAC
– –
– 0.25 kW
– 0.37 kW
0.25 kW 0.55 kW
0.37 kW 0.75 kW
0.55 kW 1.1 kW
0.75 kW 1.5 kW
1.1 kW 2.2 kW
1.5 kW 3.0 kW
2.2 kW 4.0 kW
EDK71MMXXX-020 DE/EN/FR 1.0
Note
500 VAC
2
– No I t monitoring
0.37 kW
0.55 kW
0.75 kW
1.1 kW
1.5 kW
2.2 kW
3.0 kW
4.0 kW
5.5 kW
