4. CONTROLS
6 5
8
16
1. Press to turn dash camera On-Off / Turn Night Vision LEDs On-Off
2. OK – Press to Confirm a selection / Start/Stop a recording
3. MENU – Press to open the Menu System
4. s – Press to move Up / Zoom In
5. t – Press to move Down / Zoom Out
6. MODE – Press to select Video Mode / Lock current recording
7. LCD Display
8. Speaker
9. Indicator – Green=On, Red=Charging
10. Mounting slot – Attach windscreen mount here
11. Lens
12. Night Vision LEDs
13. AV Interface – For use with AV cable (not included)
14. HDMI Interface – For use with HDMI cable (not supplied)
15. USB Interface – Use to connect to a PC with USB cable (supplied)
16. Microphone
17. Memory Card Slot – Insert Micro SD card here
18. Reset Hole – Use to reset the dash camera
RBGDC50 Instruction booklet.indb 4
4 3 13 15
10 11
14 18
9
12
1 17 2
7
