Fitting instructions

1
Remove plastic tab to activate your
BackPack.
2
If the DC mains adapter is plugged
into your R1/MR1, remove it. Slide
the BackPack over the antenna (R1)
and push the BackPack plug into the
R1/MR1 DC socket (14V DC 1.5A).
3
Secure the BackPack with the
two screws included in the set.
Tighten the screws using the Allen
key provided, taking care not to
overtighten.
4
Connect the mains adapter to the DC
socket in the BackPack.
Specifications
● 2000mAh NiMH
● Output: 9.6V (nominal)
● Input: 14VDC, 500mA
2
Please read this manual carefully before using your
BackPack and retain for future reference.
3
4
1
