5.2 TECHnICAL SPECIFICATIOn

náZEv
Type of regulator
Inlet pressure
Type of inlet
connection
Pressure gauge
Therapy flow
accurancy
Outlet pressure:
Therapy outlet
Max. nominal gas
flow
Gas flow setting
Inlet connection
thread
DENOMINA-
TION OF
THE GAS 1.0
FLOW ON
THE LABEL
MIN. GAS
0.45
FLOW
MAX. GAS
0.52
FLOW
ELITE ELH
(BULL nOSE,
PIn InDEx)
High pressure
regulator without
shut-off valve
13,5-200 bar
High pressure inlet
connection
0-200 bar
10% for gas flows
over 1l/min
20% for gas flows
under 1l/min
max. 4,2 bar
Universal
'fir-tree' type.
Pulse
See table below
Depends on the
type of gas cylinder
which it is designed
for.
1.0 1.5 2.0 2.5
0.52 0.61 0.76 0.92
0.59 0.70 0.88 1.6
7/72
ELITE ELv
(COMBInATIOn
vALvE)
High pressure
combination valve
regulator
13,5 - 200 bar
High pressure inlet
connection
0-200 bar
10% for gas flows
over 1l/min
20% for gas flows
under 1l/min
max. 4,2 bar
Universal
'fir-tree' type.
Pulse
See table below
Depends on the
type of gas cylinder
which it is designed
for.
3.0 3.5 4.0 4.5
1.7 1.23 1.38 1.54
1.23 1.41 1.59 1.77
ELITE BS
(qUICK
COUPLER)
Low pressure
regulator without
pressure gauge
3,9 - 6 bar
Low pressure quick
coupler connection
N/A
10% for gas flows
over 1l/min
20% for gas flows
under 1l/min
max. 1,6
Universal
'fir-tree' type.
Pulse - see table
below
See table below
N/A
5.0 5.5 6.0
1.69 1.85 2.00
1.95 2.13 2.30
