RF Rx SW868/915/917/922-NET-4S-A 48V
//
Montage- und Anschlussanleitung / Funk-Aktor
Mounting and wiring instructions / Wireless actuator
Instructions de montage et de câblage / Actionneur sans fil
Istruzioni di montaggio e collegamento / Attuatore wireless
Instruções de montagem e instalação / Atuador sem fio
Инструкция по монтажу и подключению / Радио-привод
Deutsch (Originalbetriebsanleitung)
Hinweise
Änderungen, die dem technischen Fortschritt dienen, vorbehalten.
Umbauten und Veränderungen am Gerät sind nicht gestattet.
Wartung und Reinigung
Wir empfehlen eine regelmäßige Wartung wie folgt:
1. Schmutzreste entfernen.
Gehäuse nur von außen reinigen. Gehäuse mit Haushaltsreinigern rei-
nigen. Keine Druckluft verwenden, um zu reinigen.
Entsorgung
- Nationale, lokale und gesetzliche Bestimmungen zur
Entsorgung beachten.
- Materialien getrennt dem Recycling zuführen.
English
Use of the mounting and wiring instructions
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer.
In case of doubt, the German language version of these instructions
shall prevail.
Scope of delivery
1 device, 1 mounting and wiring instructions, 1 carton.
Intended use
The device of type SW868 is intended for use in the European Union. It
complies with the European Union's Directive 2014/53/EU (RED) for
radio equipment.
The device of type SW915 is intended for use in Canada, USA, and Mex-
ico. It complies with the requirements of FCC Rules and IC Rules, RSS-
210. It has an approval number for the Mexican states.
The device of type SW917 is intended for use in Brazil. It complies with
the requirements of Resolucão 242/2000.
The device of type SW922 is intended for use in Japan. It complies with
the requirements of ARIB STD-T108.
The four-channel wireless actuator is used to switch electrical loads
via radio transmission. The transmission is carried out at a frequency
of 868.3, 915, 917 or 916,5 MHz. The receiver must conform to the
sWave.NET
protocol of the steute modules.
r
Mounting and wiring
Mount the device on an even surface.
Use suitable antennas only. Antenna with cable and SMA plug-in con-
nector, Mat. No. 1188958 (SW868/922) or 1188987 (SW915/917). Mount
the antenna on a metal plate. The metal plate serves as HF counter-
weight. Minimum size of metal plate: 250 x 250 mm. Observe mini-
mum sideways distance to nearest wall or disturbance source:
>300 mm. Do not bend or clamp the cable.
Minimum bending range of cable: >25 mm.
Design of wireless range
The wireless range depends on the local conditions. Because radio
signals are electromagnetic waves, the signal is attenuated on its way
from the transmitter to the receiver. This means the electrical as well
as the magnetic field strengths decrease inversely proportional to the
squared distance of transmitter and receiver (E,H~1/r²). In addition to
this natural restriction of the wireless range, further interference fac-
tors occur: Metal parts, e. g. armours in walls, metal foils of thermal
insulations or vapour deposited metal layer heat protection glass, re-
flect electromagnetic waves. Therefore, a so-called deadspot can be
found behind them. Radio waves are able to penetrate walls, but the
attenuation increases even more than in the free field.
Penetration of radio waves:
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical wireless ranges are:
Outdoor range (SW868/915/917):
Outdoor range (SW922):
Indoor range (SW868/915/917):
Indoor range (SW922):
Max. range in free field (SW868/915/917)
Max. range in free field (SW922)
Max. range indoors (SW868/915/917)
Max. range indoors (SW922)
To reach the maximum range: use the specified antennas. With other
antennas, the maximum range may differ.
Start-up and select operation mode
Requirements:
- Mount device on standard DIN rail.
- Connect cable for supply voltage 24 VDC.
- The LEDs show the operating states. If the wireless actuator and the
green MD LED MD are both switched on, then the device is ready
for use.
Switching the outputs
Switching the outputs: Set the outputs as described in the »Descrip-
tion of interface« in paragraph »RECORD.RELAIS.SWITCH« (see RF
RxT SW868/915/917/922-NET, »Description of interface«, section »Da-
taMessage«, download from www.steute.com). The outputs are always
2 / 16
90...100%
65...95%
10...90%
0...10%
approx. 450 m
approx. 150 m
approx. 40 m
approx. 20 m
approx. 700 m
approx. 230 m
approx. 50 m
approx. 25 m
